GENERAL SPECIFICATIONS
Approximate Weight (kg) 22,000 lbs. (9979)
Length – Less Forks (m) 19'1″ (5.8)
Width (m) 8'0″ (2.4)
Ground Clearance (mm) 16″ (400)
Wheelbase (m) 10'0″ (3.0)
Turning Radius (m) 13'8″ (4.2)
Overall Height (m) 7'10″ (2.4)
Frame Leveling ±10°
Fuel Capacity (L) 47 gal. (178)
CAPACITIES
Lift Capacity (kg) 6,600 lbs. (2994)
Maximum Lift Height (m) 42'0″ (12.8)
Capacity at Maximum Lift Height (kg) 6,600 lbs. (2994)
Maximum Forward Reach (m) 28'3″ (8.6)
Capacity at Max. Forward Reach (kg) 1,000 lbs. (454)
Max. Reach Below Grade (mm) 14″ (356)
COMPONENTS
Transmission Dana 3-speed Powershift
Maximum Travel Speed (km/hr) 18.8 mph (30.3)
Selective Steering 4-Wheel
2-Wheel
Crab
