Max. working height
32 ft
Max. platform height
26 ft
Platform size (stowed)
43 in x 84.38 in
Platform size (extended)
43 in x 132.38 in
Deck extension length
48 in
Overall length (with step)
90.6 in
Overall length (without step)
88.7 in
Overall width
47 in
Min. height (guardrails folded)
72.88 in
Stowed height
90.2 in
Ground clearance (stowed)
2.63 in
Ground clearance (elevated)
.75 in
Platform capacity (SWL)
1,000 lbs
Max. drive height
Max. wind speed
28 mph
Max. drive speed (elevated)
0.4 mph
Max. drive speed (stowed)
2.0 mph
Raise / lower time
50 / 58 seconds
Gradeability
25%
Inside turning radius
21 in
Outside turning radius
95 in
Tires
15 in x 5 in non-marking rubber
Controls
Proportional
Drive system
2-wheel drive
Power source
(4) 6V 240Ah AGM batteries
Charger
100 – 240VAC; 50-60Hz, 25amp
Weight
4,750 lbs
Floor load at max. capacity
210 psf
