Max. working height
32 ft
Max. platform height
26 ft
Lowered platform height
45 in
Platform size (stowed)
42 in x 84 in
Platform size (extended)
43 in x 132 in
Deck extension length
48 in
Overall length
91 in
Overall width
46 in
Min. height (guardrails folded)
70.5 in
Stowed height (guardrails up)
84.5 in
Ground clearance (stowed)
3.5 in
Ground clearance (elevated)
.75 in
Platform capacity (SWL)
1,000 lbs
Max. drive height
Max. wind speed
28 mph
Max. drive speed (elevated)
0.6 mph
Max. drive speed (stowed)
2.0 mph
Raise / lower time
54 / 32 seconds
Gradeability
30%
Inside turning radius
47.5 in
Outside turning radius
93.5 in
Tires
16 in x 5 in non-marking rubber
Weight
4,700 lbs
Overall floor load at max. capacity
191 psf
