Working height maximum - 71 ft
Platform height maximum - 65 ft
Horizontal reach maximum - 56 ft 2 in
Below ground reach - 8 ft 11 in
Platform width - 3 ft
Platform length - 8 ft
Height - stowed - 8 ft 11 in
Length - stowed - 31 ft 2 in
Length - transport (jib tucked under) - 25 ft
Width (with standard tires) - 8 ft 2 in
Wheelbase - 8 ft 2.5 in
Ground clearance - center - 1 ft 2.5 in
Lift capacity - 500 lbs
Platform rotation - 160°
Vertical jib rotation - 135°
Turntable rotation - 360° continuous
Turntable tailswing - 4 ft
Drive speed - 4WD stowed - 3.0 mph
Drive speed - raised or extended - 0.68 mph
Gradeability - 4WD - stowed - 45%
Turning radius - inside - 7 ft 9 in
Turning radius - outside - 18 ft 9 in
Controls - 12 V DC proportional
Power source - Gas/LPG
Hydraulic tank capacity - 45 gal
Fuel tank capacity - 35 gal
Weight - 4WD - 22,270 lbs
