Working height - 61 ft 3 in
Platform height - 55 ft 3 in
Horizontal outreach (from centerline) - 33 ft 5 in
Horizontal outreach (from edge of footpad) - 27 ft 4 in
Up and over height - 23 ft 1 in
Lift capacity - 500 lb
Length - stowed - 23 ft 8 in
Width stowed - 5 ft 7 in
Height stowed - 6 ft 9 in
Platform size - 4 ft 1 in x 2 ft 9 in
Widest Point - 14 ft 8 in
Turntable rotation - 350° non-continuous
Jib - length - 4 ft 3 in
Jib - Vertical Motion - 150° (+ 70 / - 80)
Tow speed rating - 65 mph
Leveling capability - 12.5 °
Power source - 4 x 6v 245amp-hr
Tongue weight (no options) - 335 lb
Weight (no options) - 4,800 lb
